American Audio VMS 5 - 5-Kanal Midi Dj Kontrol Birimi
American Audio VMS 5 - 5-Kanal Midi Dj Kontrol Birimi
Midi Controller with 4 USB / Analog selectable MIDILOG™ (Midi & Analog) channels
All audio control faders, knobs, switches, and buttons smoothed - eliminates popping, wiper noise, and zipper noise
On/Off soft startup and turnoff
Gain/treble/mid/bass EQ on all MIDILOG™ channels
2 phono/line selectable analog channels
Two microphone channels with illuminated on/off switches and gain/treble/mid/bass EQs
On/off cueing on each MIDILOG™ channel
Split cueing headphones with rotary mix control
Illuminated rubber knobs for ease of use in dark environments
Solid 1.6mm thick faceplate for extra durability
Panel mounted rotary knobs
Full analog mixer operation if the computer crashes or with external power supply
Innofader replaceable crossfader compatible (sold separately)
Crossfader curve control
Crossfader assign and reverse
Q-Start crossfader controlled startup for 2 external audio players
Master and Booth outputs with L/R balance
Balanced Master outputs
12 position stereo master output VU meter
Dimensions (LxWxH): 19”x12.75”x1.5” / 482x325x40mm
Weight: 13 lbs. / 6 kg.
MIDI
Built-in mouse pad
Long life MIDI assignable touch strips
Two 10- bit resolution pitch sliders
62 assignable MIDI buttons and switches
50 MIDI buttons have LED illuminations, including 18 with dual blue/red LEDs
4 assignable rotary encoders
34 assignable rotary controllers
5 assignable linear fader controllers
Dual MIDI controls on all buttons and switches
Dual 2000 point resolution touch sensitive turntable scratch controllers
AUDIO
24-bit 48 kHz analog audio
16-bit 44.1kHz USB audio
10-bit resolution on all analog fader controls
THD <0.1%*
Channel separation >60dB*
S/N ratio >85dB*
Analog channel audio latency < 1msec
Selectable USB modes: 4 in 4 out mode for running software effects on phono/line analog channels or 2 in 8 out mode for running 4 software channels and master recording
2 msec response on all buttons
4 msec response on all rotary and linear faders
1 msec USB latency
