Compressor: Compression is a very good effect for overall use, it smoothes out your uneven dynamics, increases sub tones which otherwise would stay too weak in the overall sound. It also gives more depth, body and sustain for a fuller sound. This is great for especially solos. Just set the level knob to match the desired solo level. For more compression turn the compress knob clockwise, and adjust your level to match the bypass level.

Overdrives: Drive 1 is the crunch channel, Drive 2 the high gain channel. To enter drive 1, press the drive switch and set the level to match the bypass level. The tone knob works like a high cut filter. Set the knob at full clockwise for high crisp tone or for warmer and rounder tone, turn the tone knob counter clockwise. To enter drive 2 leave the drive switch on and press the select switch. The level and tone knobs are the same on both channels.

Vintage Chorus: The Vintage Chorus is a very useful effect to make your tone fat round and singing, an effect very often used in loads of hit songs from the early 7o´s and up. The Speed knob set the speed of the modulation, from slow swirl to fast Leslie like tones. the Depth knob determines the amount of effect wish.

Echo: The echo effect is designed to emulate the old vintage tape echo units, with all that they had in low-fidelity noise and distortion. It has extremely musical and warm echo, so don't expect any clean sterile digital delay here. To enter the echo mode press the echo switch and set the echo level on the echo knob. Turn clock wise for more effect. Turn the repeat knob clock wise for more repeats. The tone knob works like a filter with clear crisp echo's in the full clock wise position and warmer vintage style echo when turned counter clockwise. The echo time is set on the tempo tap switch and it goes up to 1000 milliseconds. Please note that once disconnected from power, the echo time will revert to the shortest time.

Loop: The loop is a serial loop placed between the overdrives and chorus, so it's possible to add another of your favorite distortion boxes with the compressor and overdrive in front of it, and the chorus and echo after it. It is also the right place to put in another modulation effect like a tremolo, flanger orphaser. The loop has low impedance out and high impedance return.

The Quattro is not true bypass, however, the high quality output buffer circuitry ensures noise free operation with long cabling from unit to amplifier, even on large stages.

Power:100 or 115 or 230 VAC 50-60Hz
Power consumption:6 Watts
S/N ratio:56dB
Input impedance:1M Ohm
Output impedance:100 Ohm
Compression range:from 1:1 to 1:00
Gain Range Compressor:+-20dB
Gain overdrive max:89dB
Depth variation tremolo:+-6dB
Echo time max:1000 m.sec
Send impedance loop:200 Ohm
Return impedance loop:1M Ohm
Dimension:410(D) 160(W) 70(H)
Weight: 2,0Kg
