dB Technologies IG1T 2x6.5 inch 800W İki Yollu Aktif Kabin
Stokta Var!
dB Technologies IG1T 2x6.5 inch İki Yollu Aktif Kabin Hoparlör 800 Watt
TheIG1T INGENIA 2-Way Active SpeakersfromdB Technologiesfeatures 2 x 6.5" woofers, a 1" compression driver, and is equipped with a 400W RMS Digipro G3 digital amplifier. It combines high power, lightweight design, and SMPS technology with PSU auto-range. It is equipped with an infrared system in the two handles on top and bottom sides. The horn of the IG1T is horizontally symmetric and vertically asymmetric (narrower in the upper part and wider in the lower). The DSP doesn't act only on the compression driver, but also on woofers, ensuring maximum intelligibility and transparency in the whole frequency range.
2-way active speaker
2 x 6.5” woofer; 1” compression driver
400W RMS class-D Digipro G3 amplifier
Asymmetrical vertical coverage
Digital steering coverage
Element position detection
Speakers with neodymium magnet
User-friendly interface (OLED-encoder)
Unique speaker lock system
Delay on board
Microphone HPF and notch filter (variable frequency)
- Applications
Compact live sound reinforcement system
Permanent installation in theatres, houses of worship, convention centers
Portable PA, retail, clubs, ballrooms, houses of worship, corporate AV, live theatre
| System Specifications | |
|---|---|
| Speaker Type | 2-way active speaker |
| Acoustic Specifications | |
|---|---|
| Frequency Response | -10 dB: 85 to 20000 Hz -6 dB: 92 to 19200 Hz |
| Maximum SPL | 128 dB |
| High Frequency Drivers | Size: 1.0, 1.4", voice coil (2.5, 3.6 cm) Directivity (H x V): 100 x 80° (+15 /- 65°) Type: Neodymium compression driver |
| Horn | Vertical asymmetric |
| Crossover Frequency | 2100 Hz |
| Low Frequency Drivers | 2 x 6.5" (16.5 cm), 2.0" (5.1 cm), voice coil Type: Neodymium |
| Amplifier | |
|---|---|
| Technology | Digipro G3 |
| Class | Class D |
| RMS Power | 400 W |
| Peak Power | 800 W |
| Processor | |
|---|---|
| Controller | DSP 56-bit |
| Converter | AD / DA: 24-bit / 48 kHz |
| Limiter | Peak, thermal |
| Input | |
|---|---|
| Signal Input | 1 x Combo IN (XLR + Jack 6.3 mm) |
| User Interface | OLED display and rotative knob with switch |
| Signal Output | 1 x XLR link out |
| Service Port | Mini USB |
| Connector | Mains: New Neutrik NAC3PX |
| Features | |
|---|---|
| Positioning | Self-rotating display Accelerometer Infrared communication and display mirroring 10 / 5 / 0 / -5 / -10° digital steering |
| Equalizer | Acoustic correction (Low / high shelving, mid attenuation) Microphone HPF and notch filter (variable frequency) |
| Delay | On Board: Stage Alignment: 49.2' (15.0 m) System Delay: 143.4' (43.7 m) |
| Mechanics | |
|---|---|
| Housing | Polypropylene PP reinforced |
| Grille | Full / invisible screws; flyable |
| Handles | 1 x Top 1 x Bottom |
| Pole Mount | Standard D36 mm |
| Dimensions (W × H × D) | 7.68 x 21.10 x 10.67" (19.50 x 53.59 x 27.10 cm) |
| Weight | 23.37 lb (10.60 kg) |
