Electro Voice Zx3-90B 12 inch 600/1200 Watt Pasif Kabin Hoparlör

Electro Voice Zx3-90B 12 inch Pasif Kabin Hoparlör 600/1200/2400 Watt

OVERVIEW

When it comes to problem and solution versatility, the ZX3 is in a class of its own. In addition to the highest performance drivers available, a complete range of optional accessories allow the ZX3 to be easily and precisely configured in multiple box arrays, mounted on trusses or tripods, deployed as monitors, or used as system mains with a subwoofer. The optional accessories include the CB-5 array kit, MB3 wall and ceiling-mount bracket, HA-3 handle adapter for use with the VSA-1 strong arm mount, and the TCA-1 truss clamp adapter.

Housed in a stylish yet rugged injection-molded enclosure, the ZX3 shares the same functionality as the larger ZX5, with 90° x 50° or 60° x 60° horn dispersion patterns, 45° or 55° monitor angles, passive or bi-amp operation, and seven M8 rigging points. The ZX3 comes in a black finish.

DVX3121 12" LF transducer with forced-air cooling

ND2 2" voice coil, 1" exit neodymium

Compression driver

90° x 50° coverage pattern

600W continuous (2400W peak) power handling

High sensitivity, 131 dB maximum SPL

Adjustable monitor angle (45° or 55°)

2 Anchor plates for single stud fittings and

7 Integral suspension points

Available in black or white

Passive/biamp selectable

SPECIFICATIONS

Frequency response (-3dB): 58 - 15000 Hz
