Bluetooth and Wi-Fi
Display
Built-in display : fluorescent
Network internet
Functionality : Internet radio playback, digital audio playback, digital photo playback
Audio
Surround System Class : 7.2 channel
Amplifier Output Details
100 Watt - 8 Ohm - 20 - 20000 Hz - THD 0.08% - 2 channel(s) ( front )
100 Watt - 8 Ohm - 20 - 20000 kHz - THD 0.08% - 1 channel(s) ( center )
100 Watt - 8 Ohm - 20 - 20000 kHz - THD 0.08% - 2 channel(s) ( surround )
100 Watt - 8 Ohm - 20 - 20000 kHz - THD 0.08% - 2 channel(s) ( surround back )
140 Watt - 6 Ohm - at 1 kHz - THD 0.7% - 2 channel(s) ( front )
140 Watt - 6 Ohm - at 1 kHz - THD 0.7% - 1 channel(s) ( center )
140 Watt - 6 Ohm - at 1 kHz - THD 0.7% - 2 channel(s) ( surround )
140 Watt - 6 Ohm - at 1 kHz - THD 0.7% - 2 channel(s) ( surround back )
-Sound Output Mode:Surround Sound
-Built-in Decoders: DSD decoder, DTS 96/24, DTS Express, DTS Neo:6, DTS decoder,
DTS-ES Discrete 6.1, DTS-ES Matrix 6.1, DTS-HD High Resolution, DTS-HD Master Audio,
Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II,
Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD
-Sound Effects:Cinema EQ, Loudness
-Digital Sound Processor (DSP):Yes
-DSP Presets:Game, Movie, Music
-Input Impedance:47 Ohm
-Input Sensitivity:200 mV
-Bass Control : Yes
-Treble Control : Yes
-Additional Features : Apple AirPlay support, Audio Return Channel (ARC),
Audyssey Dynamic EQ, Audyssey Dynamic Volume, Audyssey MultEQ XT, Bi-Amplifying,
Bluetooth audio streaming, Deep Color, compressed music enhancer, dual-zone capability,
iPod/iPhone ready, smartphone remote controlled, source direct, x.v.Color
Amplifier Output Details
100 Watt - 8 Ohm - 20 - 20000 Hz - THD 0.08% - 2 channel(s) ( front )
100 Watt - 8 Ohm - 20 - 20000 kHz - THD 0.08% - 1 channel(s) ( center )
100 Watt - 8 Ohm - 20 - 20000 kHz - THD 0.08% - 2 channel(s) ( surround )
100 Watt - 8 Ohm - 20 - 20000 kHz - THD 0.08% - 2 channel(s) ( surround back )
140 Watt - 6 Ohm - at 1 kHz - THD 0.7% - 2 channel(s) ( front )
140 Watt - 6 Ohm - at 1 kHz - THD 0.7% - 1 channel(s) ( center )
140 Watt - 6 Ohm - at 1 kHz - THD 0.7% - 2 channel(s) ( surround )
140 Watt - 6 Ohm - at 1 kHz - THD 0.7% - 2 channel(s) ( surround back )
-Sound Output Mode:Surround Sound
-Built-in Decoders: DSD decoder, DTS 96/24, DTS Express, DTS Neo:6, DTS decoder,
DTS-ES Discrete 6.1, DTS-ES Matrix 6.1, DTS-HD High Resolution, DTS-HD Master Audio,
Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II,
Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD
-Sound Effects:Cinema EQ, Loudness
-Digital Sound Processor (DSP):Yes
-DSP Presets:Game, Movie, Music
-Input Impedance:47 Ohm
-Input Sensitivity:200 mV
-Bass Control : Yes
-Treble Control : Yes
-Additional Features : Apple AirPlay support, Audio Return Channel (ARC),
Audyssey Dynamic EQ, Audyssey Dynamic Volume, Audyssey MultEQ XT, Bi-Amplifying,
Bluetooth audio streaming, Deep Color, compressed music enhancer, dual-zone capability,
iPod/iPhone ready, smartphone remote controlled, source direct, x.v.Color
Networking
Internet Streaming Services : Flickr, Last.fm, Spotify, vTuner
DLNA : Yes
Tuner
Preset Station Qty : 56
Supported RDS Functions : PS, PTY, RT, TP
Miscellaneous
Built-in Clock : sleep timer
Equalizer
Equalizer : Yes
Equalizer Type : digital graphic
Equalizer Band Qty : 9 bands
Equalizer Center Frequencies : 1000 Hz, 125 Hz, 16000 Hz, 2000 Hz, 250 Hz, 4000 Hz, 500 Hz, 63 Hz, 8000 Hz
Signal processing
HDMI Pass-Through : up to 4K
Video Conversion/Scaling : HDMI to HDMI scaling, analog to HDMI up conversion
Upscaling via HDMI : up to 4K
Accessories
Included Accessories : AM antenna, FM antenna, auto calibration microphone, universal remote control
Power
Power Consumption Operational : 650 Watt
